Description

Kolida K2 RTK GNSS

Kolida K2 RTK GNSS System

  Powerful GNSS Chip

New generation of powerful GNSS mainboard K803 with 1598 channels enables K2 to support a wide range of satellite signals, including GPS, GLONASS, BeiDou,Galileo, QZSS, SBAS, etc, as well as Galileo HAS and BDS PPP.

8-15 km Radio Range

K2 has an built-in transceiver radio, the frequency can be figured from 410 to 470 Mhz. The typical working range of theradio is 8-15km. Farlink Pro protocol is available in 2025.

Barrier-Free Measurement

Built-in 7.4V 6800mAh high-capacity battery, the battery life is more than 15 hours in rover mode. one charge, meets all-day work. The battery cell can be recharged with long life, the performance is more secure and reliable.

WiFi and Web UI

By connecting through the integrated WiFi of K2, you can logon an user-friendly management platform on the browser of your phone or computer. All status monitoring and parameter settings can be achieved in a fast and easyway.

IMU Tilt Survey

Built-in lMU compensator, correct the coordinates according to the tilt direction and angle of the centering rod automatically within 60°, assist you quickly and accurately survey or stake out points without leveling the pole. It improves working efficiency by 20-30%.

Linux OS

Powered by the new generation of embedded Linux operating system, K2 has a greatly improved RTK performance and efficiency. A unique core processing mechanism is able to response to more than one command at each time.
